At least 25% greater WLL than traditional Grade 8 products.
Testing according to DIN PAS 1061 and ASTM A952/A 952M.
Proof Load tested at 2.5 times the WLL with certification for each batch manufactured. Fatigue rated to 20,000 cycles at 1.5 times the WLL.
Tempering temperature minimum 400°C.
Enables full WLL while in use, thanks to supporting wings which prevent chain link deformation.
- Material: Quenched and Tempered Alloy Steel.
- Marking: According to standard, Size, grade, manufacturer ID, traceability.
- Temperature range: -40ºC up to +200°C (without reduction in WLL).
- Finish: Painted.
- Standard: EN 1677-1
- Note: Not for use with Omega Link
- Safety factor: 4:1
- Grade: 10
