POWERTEX Wire rope grip PWRG is approved for lifting when assembly is made according to the user instructions.
Designed for use with six-stranded right-hand lay ropes in 6x19 (M) and 6x36 classes and right-hand langs lay wire rope in 8x19 class up to 1960 N/mm², with fibre core and a steel core.
Correctly mounted the assembly will withstand 80% of the steel wire ropes minimum breaking strength.
- Safe - The grips are designed to assure high friction between wire rope and grip
- PWRG is symmetrical and can be turned as preferred
- Quick and easy to use
- Quick mounting thanks to the recessed bolt head seats that hold the bolt while tightening the nuts
- Low maintenance thanks to galvanization of grips and Dacrotized bolt and nuts
- Tested according to 13411-5
- Features: PWRG-4 and 6 are drop forged. PWRG-8, 10, 12, 16, 20, 25, 35 are casted.
- Finish: Galvanized.
- Warning: Not for use with compacted or hammered wire ropes. It is not recommended to use plastic covered ropes for lifting purposes with wire rope grips
